Can-Am Commander rear raked a-arms
Can-Am Commander rear raked a-arms
Couldn't load pickup availability
These control arms are constructed from 0.250" wall DOM and allow for 35-37" tall tires depending on model. Arms are portal compatible and reuse all OEM hardware. Bushings and grease fittings are not included unless selected. Both upper arms feature patented adjustability for camber adjustment at ride height without removal.
Important: OEM bushings cannot be reused from factory a-arms.
INCLUDED:
Passenger side upper arm
Passenger side lower arm
Driver side upper arm
Driver side lower arm
Upper 110mm hub bolt/nut (2 pcs)
FITMENT:
64" Model (OEM tie rod bar is 14"):
2021-Current Commander 1000R XT
2021-Current Commander 1000R XT MAX
2021-Current Commander 1000R XTP
2021-Current Commander 1000R XTP MAX
2021-Current Commander 1000R XMR
62" Model (OEM tie rod bar is 11.5"):
2021-Current Commander 700/1000R DPS
2021-Current Commander 700/1000R XT (Non Max)
2021-Current Commander 1000R DPS MAX
WARRANTY: Arms are covered under limited lifetime warranty for the original purchaser. All warranty claims must include purchase date and order number and be sent in for examination.
