These arms are constructed from 0.250" wall USA DOM and allows for a 35-37" tall tire depending on model. Arms are portal compatible and allow for all OEM hardware to be reused. Arms do not include bushings (unless selected below) or grease fittings; you will reuse OEM or aftermarket. Both upper arms utilize our patented adjustability to allow the camber to be adjusted at ride height without removing the arms from the machine.
INCLUDED:
PASSENGER SIDE UPPER ARM
PASSENGER SIDE LOWER ARM
DRIVER SIDE UPPER ARM
DRIVER SIDE LOWER ARM
UPPER 110mm HUB BOLT/NUT (2 PCS)
FITMENT:
64" MODEL : (OEM tie rod bar is 14")
2019-CURRENT Maverick Sport XMR
2019-CURRENT Maverick Sport XXC
2019-CURRENT Maverick Sport XRC
60" MODEL : (OEM tie rod bar is 11.5")
2019-CURRENT Maverick Sport 1000 Base
2019-CURRENT Maverick Sport 1000/1000R DPS
2019-CURRENT Maverick Sport 1000R DPS Max
Warranty: Arms are covered under a limited lifetime warranty for original purchaser. All warranty claims must be sent in for examination with purchase date and order number.
